Fibre-cement corrugated sheets are made according to the technology NT (not containing asbestos) (hereinafter - fibre-cement corrugated sheets) unpainted and painted and parts for them are designed for device attic roofs of houses and buildings. Fibre-cement products are reliable and durable, with low thermal conductivity, significant frost, fire-safe (refer to the material of non burnable) well withstand the aggressive action of the environment, are resistant to high and low temperatures, solar radiation, humidity extremes, snow loads, not corrode and decay. Well protected from noise, rain and wind. It’s not condensed moisture under them, steam isn’t necessary. Roofs are easy to install and economical, requires minimal expenditure timber, hold the roof in good condition is simple and does not require large additional costs.
Features:
NOVELTY!!!!
SHEETS fiber-cemen corrugated coloured, lower price; smaller dimension – sophisticated look of the roof; thinner – less weight – easier roofing.
Sheets ECO-DACH and asbestos-cement coloured sheets. Main parameters. | ||
Parameters of the sheets | ECO-DACH
(asbestos-free coloured sheets) |
|
Dimensions of the sheet (length, width, thickness),mm | 875х475х4.7 | |
Height of the wave, mm | 40 | |
Pitch of the wave, mm | 150 | |
Amount of the waves | 3,5 | |
Living space of the sheet, m² | 0,33 | |
Weight of 1m² of the roofing, kg | 11 | |
Number of sheets for covering of 10 square meters of roof, pcs. | 30 |
Existing sizes of the slate compared to asbestos-cement sheets.
JSC “Ivano-Frankivskcement” offers sheets ECO-DACH and asbestos-cement sheets painted in burgundy and dark brown colours. According to the wishes of customers, JSC “Ivano-Frankivskcement” has the ability to produce colored sheets of the CE profile (Euro profile). Parameters of the profile: length – 875-2000 mm; width – 1097mm; sheet’s thickness – 5,8-6,3 mm; wave height – 51 mm; pitch of the wave – 177mm; the number of waves – 6.5.
Sheets ECO-DACH and asbestos-cement coloured sheets. Main parameters. | ||
Parameters of the sheets | ECO-DACH
(asbestos-free coloured sheets) |
asbestos-cement coloured sheets (АТ) |
Dimensions of the sheet (length, width, thickness),mm | 1750х1130х5,8
1000х1130х5,8 |
1750х1130х5,4
1000х1130х5,4 |
Height of the wave, mm | 40 | 40 |
Pitch of the wave, mm | 150 | 150 |
Amount of the waves | 8 | 8 |
Living space of the sheet, m² | 1750х1130х5,8 – 1,6 m²
1000х1130х5,8 – 0,88 m² |
1750х1130х5,8 – 1,6 m²
1000х1130х5,8 – 0,88 m² |
Sheet’s weight, kg | 1750х1130х5,8 – 21,5 kg
1000х1130х5,8 – 12,5 kg |
1750х1130х5,8 – 22,5 kg
1000х1130х5,8 – 12,9 kg |
Number of sheets on the pallet, pcs. | 115 | 110 |
